Sales Drawing of a Schroeder DD25 Element
Length: 9.7 (246mm)
OD: 2.6 (65mm)
ID: 1.1 (28 mm)
OD: 2.6 (66mm)
Flow Direction: OUTSIDE-IN Seal Material: BUNA N Seal Type: GROMMET Bypass Valve: NONE End Cap Material: STEEL Support Tube Material: STEEL
Media Type: CELLULOSE Micron Rating: 25 Element Collapse Rating: 150 PSID Operating Temperature Range: -20 F TO 225 F (-29 C TO 107 C)
These drawings, specifications and the ideas contained herein are the exclusive property of Schroeder Industries and are confidential. These documents shall not be copied or reproduced in part or in full as a basis of design, manufacture or sale; and shall not be used in any way detrimental to the interest of this company. They are subject to return upon request.
